Home > Products > FORKLIFT > FORKLIFT WITH ATTACHMENT > Niuli 3ton 360 degree attachment diesel power Rotator forklift attachemnt Rotator

Niuli 3ton 360 degree attachment diesel power Rotator forklift attachemnt Rotator

Product Description

DIESEL FORKLIFT with with Attachment Rotator    Niuli 3ton 360 degree attachment diesel power Rotator forklift attachemnt RotatorNiuli 3ton 360 degree attachment diesel power Rotator forklift attachemnt RotatorNiuli 3ton 360 degree attachment diesel power Rotator forklift attachemnt Rotator
NIULI FORKLIFT TRUCK SPECIFICATION
General 1 Model CPC30/CPCD30 CPC35/CPD35
2 Power Type   Diesel/GAS Diesel/GAS
3 Rated capacity Kg 3000 3500
4  Load center mm 500 500
Charactertic 5 Lifting height mm 3000 3000
6 Fork size mm 1070*122*40 1070*122*40
7 Mast Tilt Angle Deg 6°/12° 6°/12°
8 Front Overhang(Wheel center to fork face) mm 500 500
9 Ground Clearance(Bottom Of Mast) mm 126 126
10 Overall Dimension  Overall length(with/without fork) mm 3790/2700 3790/2700
11  Overall width mm 1230 1230
12 Mast lowered height mm 2105 2105
13 MastExtended height(with backrest) mm 4110 4110
14 Overhead guard height mm 2140 2140
15 Turning Radius(outside) mm 2415 2415
16 Min. intersecting aisle mm 2500 2500
Performance 17 Speed Travel(Full/Empty load) km/h 18/19 18/19
18 Lifting(Full/Empty load) mm/s 460/540 530/540
19 Max.Gradeability % 20 20
Chassis 20 Tire Front   28x9-15-12PR 28x9-15-12PR
21 Rear   6.50-10-10PR 6.50-10-10PR
22 Wheelbase mm 1650 1650
23 Self Weight kg 4280 4500
Transmission 24 Battery Voltage/Capacity V/Ah 12/120 12/120
25 Engine Model   C240 C490BPG QC495G
26 Manufacturer   ISUZU XinChang Quanchai
27 Rated output/r.p.m kW/rpm 34.3/2500 34.3/2500 42/2650
28 Rated torque/r.p.m Nm/rpm 137.7/1800 160/1800-2000 174/1980
29 No. of cylinder   4 4 4
30 Bore x Stroke mm 86x102 90x105 95x105
31 Displacement cc 2369 2670 2980
32  Fuel Tank capacity L 60 60 60
33 Transmission   Machanical/Hydraulic Machanical/Hydraulic
34 Operation Pressure for Attachment Mpa 17.5 17.5
 Niuli 3ton 360 degree attachment diesel power Rotator forklift attachemnt RotatorNiuli 3ton 360 degree attachment diesel power Rotator forklift attachemnt Rotator

Contact us if you need more details on Forklift With With Attachment. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Diesel Forklift With Rotators、Fork Lift. If these products fail to match your need, please contact us and we would like to provide relevant information.
